Bhavesh Steel, founded in 1995 and based in Dubai, UAE, is a prominent wear-resistant steel plate manufacturer and supplier dedicated to producing high-grade HB 450 steel plates. Known for their impeccable performance and durability, these plates are being extensively used in various industries including mining, construction, and heavy machinery. Bhavesh Steel’s dedication to quality ensures that every HB 450 plate adheres to strict international standards, giving clients the best solutions for rigorous uses. As a firm with strong distribution channels and excellence in reputation, Bhavesh Steel remains a reliable ally for companies looking for better wear-resistant supplies.
HB 450 wear-resistant steel plates are made of a low-alloyed steel with a content of carbon in the range of 0.26% to 0.40%. Major alloying elements are manganese (up to 1.60%), silicon (up to 0.60%), chromium (up to 1.40%), nickel (up to 1.50%), and molybdenum (up to 0.60%). The above elements increase the hardness and wear resistance of the steel. Mechanical properties are a Brinell hardness of 425–475 HBW, yield strength of about 1240 MPa, and elongation of about 10%. Such properties render HB 450 plates ideal for high-impact and abrasion environments.
Width :Â 500-3000mm
Thickness :Â 3-130mm
Length :Â 1000-12000mm
Heat Treatment :Â N, Q+T
Surface Paint :Â EP, PE, HDP, SMP, PVDF
| C *) | Si *) | Mn *) | P | S | Cr *) | Ni *) | Mo *) | B *) |
|---|---|---|---|---|---|---|---|---|
| Max % | Max % | Max % | Max % | Max % | Max % | Max % | Max % | Max % |
| 0.26 | 0.7 | 1.6 | 0.025 | 0.01 | 1.40 | 1.50 | 0.6 | 0.005 |
| Thickness | Hardness HBW | Typical yield strength MPa, |
|---|---|---|
| mm | min – max 1) | not guaranteed |
| 3 – 80 | 425 – 475 | 1100 – 1300 |
| (80) – 100 | 410 – 475 | 1050 – 1300 |
| (100) – 130 | 390 – 475 | 1000 – 1300 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Thickness | Size | Lbs./Sq.Ft |
|---|---|---|
| 3/16″ | 96″ x 240″ | 7.660 |
| 1/4″ | 96″ x 240″ | 10.210 |
| 5/16″ | 96″ x 240″ | 12.760 |
| 3/8″ | 96″ x 240″ | 15.310 |
| 1/2″ | 96″ x 240″ | 20.420 |
| 5/8″ | 96″ x 240″ | 25.520 |
| 3/4″ | 96″ x 288″ | 30.630 |
| 1″ | 96″ x 240″ | 40.840 |
HB 450 wear-resistant steel plates are widely applied in applications involving materials that are resistant to wear and impact. In mining, it is applied in crusher liners and chutes. They are used in the construction sector to make dump truck bodies and excavator buckets. HB 450 plates are also an essential component in the production of heavy-duty equipment such as bulldozer blades and conveyor systems. Their high hardness and toughness guarantee durability and dependability when used in applications that are exposed to rigorous conditions, thus minimizing maintenance and maximizing working efficiency.
