Bhavesh Steel is a reliable manufacturer and supplier of ASTM A709-50W Corten Steel Sheet and Plate in Dubai, UAE. With a reputation for producing high-quality steel products, we cater to various industries with precision-engineered solutions. Our ASTM A709-50W plates and sheets are produced in accordance with international standards, providing superior performance and reliability in challenging environments. With solid emphasis on timely delivery, competitive pricing, and customer satisfaction, Bhavesh Steel has emerged as a go-to destination for corrosion-resistant structural steel for construction, infrastructure, and engineering industries in the UAE and overseas.
ASTM A709-50W Corten Steel is a weathering steel that is a high-strength, low-alloy structural steel used for improved atmospheric corrosion resistance. The chemical makeup contains constituents like copper, chromium, nickel, and phosphorus, which generate a protective patina over a period of time. This steel provides superior mechanical properties with a minimum yield strength of 50 ksi and tensile strength ranging from 70 to 90 ksi. It welds and fabricates well and retains toughness even at low temperatures. These traits make ASTM A709-50W suitable for structural uses where strength, durability, and toughness against severe weather conditions are crucial.
STANDARD: ASTM A709
THICKNESS: 6-100mm
WIDTH: 900-4800mm
LENGTH: 3000-12000mm
GRADES:50W,50WT,50WF
SERVICES: Welding, Forming, Thermal Cutting
| TYPE | THICKNESS (in) | MN (wt %) | C (MAX wt %) | S (MAX wt %) | NI (MAX wt %) | P (MAX wt %) | V (wt %) | SI (wt %) | CR (wt %) | CU (wt %) |
|---|---|---|---|---|---|---|---|---|---|---|
| B | 2.00 – 3.00 | 0.75 – 1.35 | 0.20 | 0.030 | 0.50 | 0.030 | 0.01 – 0.10 | 0.15 – 0.50 | 0.40 – 0.70 | 0.20 – 0.40 |
| A | 0.1875 – 2.00 | 0.80 – 1.25 | 0.19 | 0.030 | 0.40 | 0.030 | 0.02 – 0.10 | 0.30 – 0.65 | 0.40 – 0.65 | 0.25 – 0.40 |
| GRADE | THICKNESS (in) | ELONGATION IN 8″ 2) (MIN %) | TENSILE STRENGTH (MIN ksi) | YIELD STRENGTH 1) (MIN ksi) | ELONGATION IN 2″ 2) (MIN %) |
|---|---|---|---|---|---|
| 50WT | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50W | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50WF | 0.1875 – 2.50 | 18 | 70 | 50 | 21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Bhavesh Steel is one of the most prominent manufacturers and suppliers of superior quality ASTM A709-50W Corten Steel Sheet and Plate in Dubai, UAE. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
| GRADE | THICKNESS (in) | MIN LONGITUDINAL INDIVIDUAL VALUE 1) (ft-lbs) | MIN LONGITUDINAL AVERAGE ENERGY 1) (ft-lbs) | ZONE 2 TEST TEMP | ZONE 1 TEST TEMP | ZONE 3 TEST TEMP |
|---|---|---|---|---|---|---|
| 50WT | 2.01 – 3.00 | — | 20 | 40 oF | 70 oF | 10 oF |
| 50WT | 0.1875 – 2.00 | — | 15 | 40 oF | 70 oF | 10 oF |
| 50WF | 0.1875 – 2.00 | 20 | 25 | 40 oF | 70 oF | 10 oF |
| 50WF | 2.01 – 2.50 | 24 | 30 |
| GRADE | WIDTH (in) | THICKNESS (in) | LENGTH (in) |
|---|---|---|---|
| 50WT | 72 – 120 | 0.1875 – 3.00 | 240 – 1200 |
| 50W | 72 – 120 | 0.1875 – 3.00 | 240 – 1200 |
| 50WF | 72 – 120 | 0.1875 – 2.50 | 240 – 1200 |
ASTM A709-50W Corten Steel Plate and Sheet is widely utilized in architectural and structural works where longevity and weather resistance are necessary. It is comprehensively used in the construction of bridges, highway infrastructure, load-bearing structures, and other civil works. Due to its weather-resistant outer surface, the requirement for painting is eliminated and maintenance expenses are avoided in the long run. Moreover, its visually appealing rust-like color makes it a top-rated exterior facade material, outdoor installation material, and landscape architecture material. Its high performance and cost-effectiveness make it a trusted material both in terms of functionality and design application.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
