Bhavesh Steel, founded in 1995 and having its headquarters in Dubai, UAE, is a prominent manufacturer and supplier of high-quality carbon steel SA210 A1 tubing. The seamless tubes are designed for high-performance use in high-temperature applications like heat exchangers, economizers, and steam-generating boilers. Bhavesh Steel’s focus on quality ensures that every tube is up to international standards, providing clients with long-lasting and dependable solutions for their industrial purposes. With a sound distribution network and an image of excellence, Bhavesh Steel remains the preferred partner for the steel industry.
Carbon steel SA210 A1 tube consists largely of carbon, manganese, phosphorus, sulfur, and silicon. The carbon percentage is usually from 0.06% to 0.18%, and the manganese percentage is between 0.27% and 0.63%. Phosphorus and sulfur percentages are maintained low, usually less than 0.035% and 0.035%, respectively, for improved weldability as well as lowering brittleness. Some mechanical properties are tensile strengths of 325 MPa, yield strengths of 180 MPa, and elongation percentages of 35%, depending on the grade.
| Grade: | ASME/ASTM SA179, SA192, SA210, SA178, SA214, API 5L |
|---|---|
| Size: | 1/8” NB TO 24” NB Sch 40/80/160/XXS |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Certification For Carbon | Mill Test Certificate as per EN 10204 / 3.2B |
| General Requirements | ASTM A 530/A 530M |
| Dimensional Tolerances | ANSI B 36.10 |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| Element | A/SA 210 Gr A1 |
| C | 0.27 max. |
| Mn | 0.93 max. |
| P | 0.035 max. |
| S | 0.035 max. |
| Si | 0.10 min. |
| Element | A/SA 210 |
| Tensile Strength KSI (MPa) | 60 (415) |
| Yield Strength KSI (MPa) | 37 (255) |
| Elongation min. % | 30 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel SA210 A1 Tubing in Dubai, UAE. We offer premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to timely delivery and exceptional customer service, we source the finest raw materials to ensure superior strength and performance in demanding industrial applications. Contact us today for all your Carbon Steel SA210 A1 Tubing requirements!
| Outside Diameter in MM | Cut Length in MM | |
|---|---|---|
| Over (+) | Under (-) | |
| All Sizes | 3⁄16 [5] | 0 [0] |
| Under 2 (50.8) | 1⁄8 [3] | 0 [0] |
| 2 (50.8) and over | 3⁄16 [5] | 0 [0] |
| Under 2 (50.8) | 1⁄8 [3] | 0 [0] |
| 2 (50.8) and over | 3⁄16 [5] | 0 [0] |
Carbon steel SA210 A1 tubing has extensive applications across different industries owing to its superior strength and heat transfer characteristics. In the power generation industry, these tubes find application in air preheaters, economizers, and heat exchangers for effective heat transfer and energy efficiency. They are also applied to steam-generating boilers and fossil fuel facilities for their resistance to extreme heat and pressures. Moreover, the SA210 A1 tubes also serve in water supply systems and waste heat recovery devices, which operate efficiently under harsh conditions.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
