Bhavesh Steel is a reliable manufacturer and supplier of premium Carbon Steel A423 GR 1 Tubing in Dubai, UAE. With a focus on excellence and innovation, we serve a wide range of industries by providing long-lasting and precision-crafted tubing solutions. We are famous for our prompt delivery and customer-oriented policy, and Bhavesh Steel has earned a huge reputation in the UAE as well as overseas markets. Our Carbon Steel A423 GR 1 Tubing is produced to global standards for superior performance and reliability in harsh environments, making us an engineer and builder’s first choice.
Carbon Steel A423 GR 1 Tubing contains mostly carbon, manganese, phosphorus, and sulfur, providing a balanced combination of strength and weldability. The mechanical characteristics are a minimum yield strength of 30,000 psi (205 MPa) and tensile strength of 55,000 psi (380 MPa), with satisfactory elongation and toughness. It is capable of withstanding high pressure and alternating temperature. Its construction provides consistent mechanical integrity and thus is suitable for low to moderate temperatures, particularly in applications where performance and durability are essential under long-term usage.
| Size Range | : | ½” OD to 16” OD |
| Standards | : | AASTM A 423 / ASME SA 423 |
| Grade | : | ASTM A423 GR 1 / ASME SA423 GR 1 |
| Type | : | Round, Square, Rectangle, Hydraulic, Honed Tubes |
| Length | : | Single Random, Double Random & Customize Size |
| Type | : | Weathering Steel |
| End | : | Plain End, Beveled End, Threaded End |
| Element | C, % | Mn, % | P, % | S, % | Si, % | Cu, % | Cr, % | Ni, % |
|---|---|---|---|---|---|---|---|---|
| A/SA 423 GR 1 | 0.15 max. | 0.55 max. | 0.06–0.16 | 0.060 max. | 0.10 min. | 0.20–0.60 | 0.24–1.31 | 0.20–0.70 |
| Grade | Yield Strength MPa(min) | Tensile Strength MPa | Elongation % (min) |
| Corten A | 355 | 470-630 | 20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel A423 GR 1 Tubing in Dubai, UAE. We offer premium steel materials and a wide range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel A423 GR 1 Tubing needs!
| Outside | Nominal | Wall | Inside | Weight |
| Diameter | Pipe Diameter | Thickness | Diameter | Lbs |
| Inches | Inches | Inches | Inches | Per Foot |
| 1.660 | 1-1/4 | .140 | 1.380 | 2.273 |
| 1.315 | 1 | .133 | 1.049 | 1.679 |
| 1.900 | 1-1/2 | .145 | 1.610 | 2.718 |
| 2.875 | 2-1/2 | .203 | 2.469 | 5.793 |
| 2.375 | 2 | .154 | 2.067 | 3.653 |
| 6.625 | 6 | .28 | 6.056 | 18.97 |
| 3.50 | 3 | .216 | 3.068 | 7.576 |
| 4.50 | 4 | .237 | 4.026 | 10.79 |
| 4 | 3-1/2 | .226 | 3.548 | 9.109 |
| 5.563 | 5 | .258 | 5.047 | 14.62 |
| 8.625 | 8 | .322 | 7.981 | 28.55 |
Carbon Steel A423 GR 1 Tubing has extensive application in different industries as it is strong, resistant to corrosion, and affordable. It finds extensive use in the fabrication of bridges, buildings, and structural frames. It is also utilized in power plants, refineries, and oil and gas pipelines where resistance to pressure is necessary. The tubing’s ease of welding and forming makes it specifically suitable for fabrication industries. It is also used in HVAC systems, heat exchangers, and other mechanical equipment where reliable performance under fluctuating thermal and mechanical stress is necessary.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
