Bhavesh Steel is a reputable manufacturer and supplier located in Dubai, UAE, known for its high-performance steel products, including the SA 516 GR.65N NACE HIC plates. They have built a solid reputation for sticking to international quality standards, providing corrosion-resistant steel solutions that are perfect for tough industrial settings. Their SA 516 GR.65N NACE HIC plates are specifically designed for applications that need exceptional resistance to hydrogen-induced cracking, making them a go-to choice in sour service conditions. With a strong emphasis on durability, prompt delivery, and customer satisfaction, Bhavesh Steel caters to vital sectors like oil and gas, petrochemicals, and power generation, both regionally and globally.
SA 516 GR.65N NACE HIC plates are normalized carbon steel plates crafted for pressure vessels and sour service applications. They contain up to 0.26% carbon and 0.60–1.30% manganese, with carefully controlled levels of phosphorus and sulfur to boost HIC resistance. These plates provide a minimum yield strength of 260 MPa and a tensile strength that ranges from 450 to 585 MPa. They undergo normalization to enhance notch toughness and comply with NACE MR0175 standards. Renowned for their excellent weldability and toughness, these plates are perfect for environments where resistance to hydrogen-induced cracking is crucial for maintaining long-term structural integrity.
| Grade | ASME SA 516 GR.65N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-460A/B | EN10028 P295GH | A/SA516 – Grade 65 | DIN 17155 17 MN 4 |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.65N NACE HIC Plates in Dubai, UAE. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.65N NACE HIC Plates needs!
SA 516 GR.65N NACE HIC plates are widely utilized in industries that operate in sour service environments, where high resistance to hydrogen-induced cracking and sulfide stress corrosion is vital. These plates are often used in the construction of pressure vessels, storage tanks, separators, heat exchangers, and gas processing equipment. Their superior toughness, weldability, and adherence to NACE standards make them a popular choice in oil and gas refineries, petrochemical plants, and offshore platforms. Their durability and reliability in extreme operating conditions make them the preferred material for critical infrastructure and high-risk industrial projects.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
