Bhavesh Steel has earned a solid reputation as a reliable manufacturer and supplier of Carbon Steel IS 3589 Pipes in Dubai, UAE. We take pride in our dedication to quality and dependability, offering top-notch steel piping solutions that cater to a wide range of industrial needs. With years of experience under our belt and a strong emphasis on customer satisfaction, Bhavesh Steel provides competitively priced products that adhere to international standards. Our Carbon Steel IS 3589 Pipes are perfect for high-performance applications, delivering the durability and strength required for fluid transmission and structural purposes. Clients throughout the UAE trust us for timely delivery, certified quality, and comprehensive support services.
These Carbon Steel IS 3589 Pipes are primarily made up of carbon, manganese, phosphorus, and sulfur, with carbon content usually falling between 0.20% and 0.25%. These elements enhance the pipe’s strength and weldability. The mechanical properties boast a minimum tensile strength of 410 MPa and a yield strength of 250 MPa, ensuring they can withstand pressure effectively. With a minimum elongation percentage of 23%, these pipes exhibit excellent ductility. Known for their toughness, they are well-suited for welding and forming, making them ideal for both structural and fluid handling applications.
| Size in MM | 15 Nominal Bore to 150 Nominal Bore |
| Dimension & Tolerance | Dimensions IS: 3589 = 2004 / Equivalent to BS = 1985/ 1387 |
| Specifications | IS 3589 |
| Surface Finish | Black |
| Pipe Marking | All Pipe are marked as follows: Supplier or Manufacturer’s Name, Standard, Grade, OD, Thickness, Length, Heat Number |
| Features | High Strength, Corrosion Resistant, Deformability & High Toughness |
| Length | As per Client’s requirement |
| Nominal Bore | Nominal Bore | Outer Diameter | Light | Medium | Heavy | |||
| Thickness | Weight | Thickness | Weight | Thickness | Weight | |||
| MM | IN | MM | MM | Kg/Meter | MM | Kg/Meter | MM | Kg/Meter |
| 6 | 1/8″ | 10.32 | 1.80 | 0.361 | 2.00 | 0.407 | 2.65 | 0.493 |
| 10 | 3/8″ | 17.10 | 1.80 | 0.674 | 2.35 | 0.852 | 2.90 | 1.020 |
| 15 | 1/2″ | 21.43 | 2.00 | 0.952 | 2.65 | 1.122 | 3.25 | 1.450 |
| 20 | 3/4″ | 27.20 | 2.35 | 1.410 | 2.65 | 1.580 | 3.25 | 1.900 |
| 8 | 1/4″ | 13.49 | 1.80 | 0.517 | 2.35 | 0.650 | 2.90 | 0.769 |
| 25 | 1″ | 33.80 | 2.65 | 2.010 | 3.25 | 2.440 | 4.05 | 2.970 |
| 40 | 11/2″ | 48.40 | 2.90 | 3.250 | 3.25 | 3.610 | 4.05 | 4.430 |
| 50 | 2″ | 60.30 | 2.90 | 4.110 | 3.65 | 5.100 | 4.47 | 6.170 |
| 65 | 21/2′ | 76.20 | 3.25 | 5.840 | 3.65 | 6.610 | 4.47 | 7.900 |
| 80 | 3″ | 88.90 | 3.25 | 6.810 | 4.05 | 8.470 | 4.85 | 10.100 |
| 100 | 4″ | 114.30 | 3.65 | 9.890 | 4.50 | 12.100 | 5.40 | 14.400 |
| 125 | 5″ | 139.70 | ….. | …… | 4.85 | 16.200 | 5.40 | 17.800 |
| 150 | 6″ | 165.10 | …… | ……. | 4.85 | 19.200 | 5.40 | 21.200 |
| Wall Thickness | 7 Inch Nominal Bore 193.7 Kg/Meter | 8 Inch Nominal Bore 219.1 Kg/Meter | 10 Inch Nominal Bore 273 Kg/Meter | 12 Inch Nominal Bore 323.7 Kg/Meter | 14 Inch Nominal Bore 355.6 Kg/Meter | 16 Inch Nominal Bore 406.4 Kg/Meter | 18 Inch Nominal Bore 454 Kg/Meter | 20 Inch Nominal Bore 508 Kg/Meter |
| 9.53 | …… | 51.50 | 60.24 | 73.75 | 81.21 | 93.13 | 105.00 | 117.00 |
| 4.85 | 22.59 | 25.62 | 32.07 | 38.13 | …… | …….. | ……. | ……. |
| 5.20 | 24.17 | 27.43 | 34.34 | 40.84 | …… | …….. | …….. | …….. |
| 5.60 | 26.00 | 29.28 | 36.93 | 43.93 | 48.11 | …….. | ……… | ………. |
| 7.01 | 32.27 | 36.76 | 46.43 | 55.45 | 61.82 | 69.04 | …… | …… |
| 7.94 | ….. | 41.00 | 50.95 | 61.85 | 67.98 | 77.92 | 87.80 | ……. |
| 6.35 | 29.34 | 33.28 | 41.73 | 49.67 | 54.43 | 62.35 | 70.50 | 78.50 |
| 6.00 | 27.88 | 31.53 | 39.50 | 47.02 | 51.49 | 61.00 | 69.00 | …….. |
| 8.18 | …… | 42.56 | 53.42 | 65.12 | …… | …… | …… | …… |
| 12.70 | …… | ….. | …… | …… | 107.28 | 123.30 | 139.00 | 155.00 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel IS 3589 Pipe in Dubai, UAE. We offer premium steel materials and a comprehensive range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance for industrial applications with stringent requirements. Contact us today for all your Carbon Steel IS 3589 Pipe needs!
| Nominal Bore | Outside Diameter | Light Thickness Weight | Medium Thickness Weight | Heavy Thickness Weight | |||||
| Inch | MM | Inch | MM | MM | kg/Meter | MM | kg/Meter | MM | kg/Meter |
| 1/8 | 3 | 0.406 | 10.32 | 1.80 | 0.361 | 2.00 | 2.65 | 0.493 | |
| 1/4 | 6 | 0.532 | 13.49 | 1.80 | 0.517 | 2.35 | 0.407 | 2.90 | 0.769 |
| 3/8 | 10 | 0.872 | 17.10 | 1.80 | 0.674 | 2.35 | 0.852 | 2.90 | 1.02 |
| 3/4 | 20 | 1.094 | 27.20 | 2.35 | 1.410 | 2.65 | 1.580 | 3.25 | 1.90 |
| 1.1/2 | 40 | 1.906 | 48.40 | 2.90 | 3.250 | 3.25 | 3.610 | 4.05 | 4.43 |
| 1 | 25 | 1.312 | 33.80 | 2.65 | 2.010 | 3.25 | 2.440 | 4.05 | 2.97 |
| 1.1/4 | 32 | 1.656 | 42.90 | 2.65 | 2.580 | 3.25 | 3.140 | 4.05 | 3.84 |
| 1/2 | 15 | 0.844 | 21.43 | 2.00 | 0.952 | 2.65 | 1.122 | 3.25 | 1.45 |
| 2 | 50 | 2.375 | 60.30 | 2.90 | 4.110 | 3.65 | 5.100 | 4.47 | 6.17 |
| 2.1/2 | 65 | 3.004 | 76.20 | 3.25 | 5.840 | 3.65 | 6.610 | 4.47 | 7.90 |
| 6 | 150 | 6.500 | 165.10 | – | – | 4.85 | 19.20 | 5.40 | 21.2 |
| 3 | 80 | 3.500 | 88.90 | 3.25 | 6.810 | 4.05 | 8.470 | 4.85 | 10.1 |
| 4 | 100 | 4.500 | 114.30 | 3.65 | 9.890 | 4.50 | 12.10 | 5.40 | 14.4 |
| 5 | 125 | 5.500 | 139.70 | – | – | 4.85 | 16.20 | 5.40 | 17.8 |
Carbon Steel IS 3589 Pipes find extensive use across various industries due to their strength, versatility, and resistance to corrosion. They are commonly used in water supply systems, sewage infrastructure, and oil and gas transmission. Additionally, these pipes are widely utilized in power plants, chemical processing, and fire-fighting systems. In structural engineering, they serve purposes such as scaffolding, foundation piling, and building frameworks. Their high weldability and ability to endure both internal and external pressure make them perfect for industrial piping networks and process piping. At Bhavesh Steel, we ensure that each pipe meets rigorous quality standards for dependable performance in challenging environments.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
