In Dubai, United Arab Emirates, Bhavesh Steel is a well-known producer and supplier of Carbon Steel BS3601 Pipes, providing premium piping solutions that satisfy British Standard BS3601. These pipes are renowned for their durability, precision in dimensions, and appropriateness for pressure applications involving non-alloy steel. Bhavesh Steel guarantees that every product is produced in accordance with industry standards and under stringent quality control. The business provides trustworthy carbon steel pipe solutions to the petrochemical, mechanical, water treatment, and construction industries in the United Arab Emirates and around the world, all supported by affordable prices, timely delivery, and first-rate customer service.
Low carbon (up to 0.20%) and trace elements like silicon, phosphorus, and sulphur are commonly found in carbon steel BS3601 pipes. Excellent machinability and weldability are provided by this composition. These pipes are perfect for pressure applications because of their good elongation, appropriate yield strength, and moderate tensile strength. BS3601 pipes are dependable under medium pressure conditions because they can withstand mechanical and thermal stresses. In a variety of engineering and fluid handling systems, their mechanical qualities enable cold working and bending without sacrificing structural integrity, guaranteeing longevity and long-term performance.
| Dimensions | ASTM, ASME and API |
| Thickness | 50mm to 7.00mm, custom OD and thickness available on request |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Required Length, Custom Size – according to customer’s requirement |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Types | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter | 19.05mm to 127mm |
| Wall Thickness | 0.8mm to 6.0mm |
| Length | 6mtr/ 12mtr or Cut to Length |
| Capacity | 7000 Mt/Month |
Grade | Mfg. Process | Chemical Composition(%) | ||||||||
C | Si | Mn | P | S | Ni | Cr | Mo | Others | ||
BW320 | B | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW320 | E | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW360 | E | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.050Max | – | – | – | – |
ERW430 | E | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | – |
S360 | S | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
S430 | S | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
SAW430 | A | 0.25Max | 0.50Max | 1.20Max | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
Grade
|
Tensile Test MPa or N/mm2 |
Remaks (Similar to JIS) |
Possibility Temperature |
|
|
Min Yield point |
Tensile Strength |
|||
|
BW320 |
195 |
320~460 |
– |
|
|
ERW320 |
195 |
320~460 |
– |
|
|
ERW360 |
235 |
360~500 |
(STPG370) |
|
|
ERW430 |
195 |
430~570 |
(STPG410) |
|
|
S360 |
235
225
215 |
360~550 |
(STPG310) |
|
|
S430 |
275
265
255 |
430~570 |
(STPG410) |
|
|
SAW430 |
275
265
255 |
430~570 |
(STPY400) |
|
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Nominal Pipe Size (inches) | Outer Diameter (mm) | Wall Thickness (mm) | Weight (kg/m) |
|---|---|---|---|
| 1/2 | 21.3 | 2.11 | 1.21 |
| 3/4 | 26.7 | 2.11 | 1.62 |
| 1 | 33.4 | 2.77 | 2.49 |
| 1 1/4 | 42.2 | 3.56 | 3.74 |
| 1 1/2 | 48.3 | 3.68 | 4.46 |
| 2 | 60.3 | 3.91 | 5.71 |
| 3 | 88.9 | 5.49 | 11.29 |
| 4 | 114.3 | 6.02 | 16.07 |
| 6 | 168.3 | 7.11 | 28.26 |
Jaxon Steel is a leading manufacturer and exporter of high-quality Carbon Steel BS3601 Pipes in Dubai, UAE. We offer a comprehensive range of steel solutions, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product portfolio includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliability and outstanding customer service, we are dedicated to delivering top-tier steel products designed for demanding industrial applications, ensuring long-lasting durability and superior performance. Jaxon Steel is your trusted partner for all Carbon Steel BS3601 Pipe needs.
In many different industries, carbon steel BS3601 pipes are used extensively in pressure systems to transport fluids like steam, water, air, and gases. They are perfect for general engineering and mechanical applications, especially in pressure vessels, plant piping, and boiler installations. They are utilised for structural support, fire safety piping, and HVAC systems in the building and infrastructure industries. These pipes can also be used in industrial processing plants and water treatment facilities. They are a dependable option for secure and effective fluid transport systems because of their capacity to function consistently under pressure and temperature changes.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
