Known for providing premium piping solutions that satisfy British Standards, Bhavesh Steel is a top producer and supplier of Carbon Steel BS1387 Pipes in Dubai, United Arab Emirates. Bhavesh Steel, which specialises in carbon steel products, offers BS1387 pipes that are perfect for low-pressure uses in gas, water, and aviation transportation systems. The company serves a number of industries, including industrial use, plumbing, infrastructure, and construction, with an emphasis on performance, durability, and compliance. In the UAE and abroad, Bhavesh Steel is dedicated to providing dependable goods, timely delivery, and customer-focused services.
BS1387 Carbon Steel Mild steel with a carbon content of between 0.16% and 0.20%, as well as trace amounts of silicon, phosphorus, sulphur, and manganese, is used to make pipes. Excellent formability and weldability are guaranteed by this composition. The pipes are suitable for bending and threading due to their mechanical qualities, which include good tensile strength, moderate yield strength, and adequate elongation. These pipes are perfect for low-pressure fluid transport and general mechanical applications because they provide dependable pressure handling, corrosion resistance (particularly when galvanised), and structural integrity.
| BS1387 | |||
| C | Mn | P | S |
| S,W | 0.2 | 1.2 | 0.045Max |
| BS1387 | Yield point Min Mpa | Tensile Strength Mpa | Elongation (%) |
| ≥195 | 325~460 | ≥20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and supplier of high-quality Carbon Steel BS1387 Pipe products in Dubai, UAE. Specializing in steel solutions, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product lineup features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Renowned for our reliable delivery and exceptional customer service, we are dedicated to providing top-grade steel materials that ensure durability and performance in various industrial applications. Jaxon Steel is your trusted partner for all your Carbon Steel BS1387 Pipe needs.
| Class | Nominal Diameter (DN) mm | Designation of thread Inch | Outside diameter | Thickness mm | Mass of black tube | ||
| Max mm | Min mm | Plain end kg/m | Screwed and socketed kg/m | ||||
| Light | 15 | 1/2 | 21.4 | 21.0 | 2.0 | 0.947 | 0.956 |
| 20 | 3/4 | 26.9 | 26.4 | 2.3 | 1.38 | 1.39 | |
| 25 | 1 | 33.8 | 33.2 | 2.6 | 1.98 | 2.00 | |
| 32 | 1 1/4 | 42.5 | 41 .9 | 2.6 | 2.54 | 2.57 | |
| 40 50 | 1 1/2 2 | 48.4 60.2 | 47.8 59.60 | 2.9 2.9 | 3.23 4.08 | 3.27 4.15 | |
| 65 | 2 1/2 | 76.0 | 75.2 | 3.2 | 5.71 | 5.83 | |
| 80 | 3 | 88.7 | 87.9 | 3.2 | 6.72 | 6.89 | |
| 100 | 4 | 113.9 | 113.0 | 3.6 | 9.75 | 10.0 | |
| Medium | 15 | 1/2 | 21.7 | 21.1 | 2.6 | 1.21 | 1.22 |
| 20 | 3/4 | 27.2 | 26.6 | 2.6 | 1.56 | 1.57 | |
| 25 | 1 | 34.2 | 33.4 | 3.2 | 2.41 | 2.43 | |
| 32 | 1 1/4 | 42.9 | 42.1 | 3.2 | 3.10 | 3.13 | |
| 40 | 1 1/2 | 48.4 | 48.0 | 3.2 | 3.57 | 3.61 | |
| 50 | 2 | 60.8 | 59.8 | 3.6 | 5.03 | 5.10 | |
| 65 | 2 1/2 | 76.6 | 75.4 | 3.6 | 6.43 | 6.55 | |
| 80 | 3 | 89.5 | 88.1 | 4.0 | 8.37 | 8.54 | |
| 100 | 4 | 114.9 | 113.3 | 4.5 | 12.2 | 12.5 | |
| 125 | 5 | 140.6 | 138.7 | 5.0 | 16.6 | 17.1 | |
| 150 | 6 | 166.1 | 164.1 | 5.0 | 19.7 | 20.3 | |
| Heavy | 15 | 1/2 | 21.7 | 21.1 | 3.2 | 1.44 | 1.45 |
| 20 | 3/4 | 27.2 | 26.6 | 3.2 | 1.87 | 1.88 | |
| 25 | 1 | 34.2 | 33.4 | 4.0 | 2.94 | 2.96 | |
| 32 | 1 1/4 | 42.9 | 42.1 | 4.0 | 3.80 | 3.83 | |
| 40 | 1 1/2 | 48.8 | 48.0 | 4.0 | 4.38 | 4.42 | |
| 50 | 2 | 60.8 | 59.8 | 4.5 | 6.19 | 6.26 | |
| 65 | 2 1/2 | 76.6 | 75.4 | 4.5 | 7.93 | 8.05 | |
| 80 | 3 | 89.5 | 88.1 | 5.0 | 10.3 | 10.5 | |
| 100 | 4 | 114.9 | 113.3 | 5.4 | 14.5 | 14.8 | |
| 125 | 5 | 140.6 | 138.7 | 5.4 | 17.9 | 18.4 | |
| 150 | 6 | 166.1 | 164.1 | 5.4 | 21.3 | 21.9 | |
| NOTES: 1) Dimensions and masses are accordance with ISO R65 2) Hydrostatic test pressure 50 kg/cm2 | |||||||
Applications needing low-pressure piping and structural support frequently use carbon steel BS1387 pipes. They are utilised in the construction sector for scaffolding, fencing, and gas and water distribution lines. These pipes are used in plumbing systems to transport fluids in both residential and commercial settings. Light structural frameworks, fire safety systems, and air and steam pipelines are examples of industrial applications. Additionally, BS1387 pipes are used in greenhouses, warehouse buildings, and agricultural irrigation. They are a popular option for adaptable, long-lasting piping systems in a variety of industries due to their affordability, durability, and adherence to established standards.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
