Bhavesh Steel is a renowned producer and supplier of Carbon Steel API X65 5L PSL 1 Pipes in Dubai, UAE. Dedicated to quality and accuracy, we offer long-lasting, high-performance piping solutions that adhere to international standards. Our pipes are well-known for their excellent strength, corrosion resistance, and long lifespan. Supplying major industries in the UAE, Bhavesh Steel provides prompt delivery and tailor-made solutions to suit different project requirements. For oil and gas, construction, or industrial sectors, we are your go-to supplier of API X65 5L PSL 1 carbon steel pipes.
Carbon Steel API X65 5L PSL 1 Pipes consist mainly of carbon, manganese, phosphorus, sulfur, and silicon. These components increase the strength and toughness of the pipe. The standard yield strength is 450 MPa, with a tensile strength of 535 MPa, providing superb performance under pressure. The pipes are well weldable and formable and are suitable for high-pressure use. They have a balanced chemical composition and mechanical properties that guarantee reliability and safety under challenging environments as stipulated in the API 5L standard.
| Standard | ISO 3183 L450/ API 5L X65 |
| Grade of material | X65 / L450 (N, M, Q, R) |
| PSL Level | |
| API 5L X65 PSL1 Seamless Pipe (OD) | 21.3 – 660mm ( Inch 1/2” – 26”) |
| X65 Steel LSAW / DSAW | 16’OD TO 54″ OD (8 MM TO 50 MM THK) |
| X65 Carbon Steel SAW | 16″ – 100″ NB |
| API 5L X65 PSL1 ERW and HFW | 1/2” NB – 24” NB |
| Coating for API 5L X65 PSL1 Line Pipe | 3PP, Anti-Rust Oil, CRA clad, FBE, lined pipe, Varnished, Black Painting, 3PE, 3LPE, Galvanized, |
| API 5L Grade X65 Pipe end | Cut Grooves, Square Cut, Grooved, Vibrator Grinding, Plain end (PE), Chamfering, Coupling, Screwed, Pub Joints, Deburring, Thread Cutting, Flanged Ends, Socket, Squared Ends, Threaded Ends (Male & Female), Buttweld, Beveled End (BE) |
| Cutting Facility | Laser Cutting, Sawing, Tapping, Water Jet Cutting |
| Equivalent Standards | JIS, DIN, NFA, BS, CSA, GOST, AWWA, KS, UNI, AISI, IS, EN, API, SAE, ANSI, ISO, ASTM, GB, SS |
| Grade X65 PSL1 Pipe Length | DRL, SRL, 20FT, 40FT, Single Random Length (SRL), Double Random Length (DRL), and Fixed Length 5.8 Meter, 12.0 Meters (40FT), 6.0 Meters (20FT), 11.8 Meters, |
| API 5L X65 Wall Thickness | SCH-STD, SCH160, SCH80, SCH-XXS, SCH-XS, SCH40 |
| Manufacturing process | Welded, Seamless, Electro Fusion Seam Welded (EFSW), Hot Finish Seamless (HFS), Longitudinally Submerged Arc Welded (LSAW), Cold Drawn Seamless (CDS), Electric Resistance Welded (ERW), Horizontal Submerged Arc Welded (HSAW), Extrusion, Submerged Arc Welded (SAW) |
| Mass fraction, based upon heat and product analysis a | |||||||
| CS PIPE | |||||||
| C | Mn | P | S | V | Nb | Ti | |
| maxb | max.b | min. | max. | max. | max. | max. | max. |
| 0.28e | 1.40e | – | 0.030 | 0.030 | f | f | f |
| Y.S | T.S | ELONGATION |
| Mpa(psi) | Mpa(psi) | |
| min | min | min |
| 415(60 200) | 520(75 400) | F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| API 5L X65 Pipe types | API 5L X65 Pipe Size (mm) | Tolerances | |
|---|---|---|---|
| Hot rolled API 5L X65 Seamless Pipe | OD | <50 | ±0.50mm |
| ≥50 | ±1% | ||
| WT | <4 | ±12.5% | |
| ≥4～20 | +15%, -12.5% | ||
| >20 | ±12.5% | ||
| Cold drawn API 5L X65 Seamless Pipe | OD | 6～10 | ±0.20mm |
| 10～30 | ±0.40mm | ||
| 30～50 | ±0.45 | ||
| >50 | ±1% | ||
| WT | <1 | ±0.15mm | |
| >1～3 | + 15%, – 10% | ||
| >3 | + 12.5%, – 10% | ||
Bhavesh Steel is a leading supplier of high-quality Carbon Steel API X65 5L PSL 1 Pipes products in Dubai, UAE. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
Carbon Steel API X65 5L PSL 1 Pipes are used widely in the oil and gas sector for petroleum, natural gas, and water pipeline transportation. They have high strength and long service life, which makes them ideal for both onshore and offshore projects. They find applications in the energy sector apart from the above-mentioned one. They are utilized in structural and mechanical systems like refineries, petrochemical complexes, and infrastructure development. These pipes are also selected because they are resistant to extreme environmental conditions and thus suited for application in deserts, sea areas, and areas with high temperatures. Bhavesh Steel provides quality pipes customized for various industrial applications.
