Bhavesh Steel is a leading producer and exporter of high-grade Carbon Steel AISI 1045 Angle products in Dubai, UAE. Committed to excellence, we provide a wide variety of carbon steel angles designed to cater to the particular requirements of industries like construction, automobile, and machinery production. We source our products from recognized mills and subject them to strict quality control procedures to provide international-quality standards. Regardless of whether you need regular sizes or special specifications, Bhavesh Steel is your reliable friend for long-lasting and dependable carbon steel angle solutions in the UAE.
AISI 1045 is a medium carbon steel with a carbon level of between 0.43% and 0.50%. Its composition consists of about 0.60% to 0.90% manganese, 0.15% to 0.35% silicon, and negligible phosphorus and sulfur content. This steel material provides a tensile strength of between 570 MPa and 700 MPa, yield strength of between 310 MPa and 450 MPa, and elongation at break of between 14% and 16%. The Brinell hardness is generally between 170 and 210 HB. These characteristics suit AISI 1045 for use in applications that demand a combination of strength, toughness, and machinability. MFG Shop
| Specifications | : | AISI A1045 |
| Dimensions | : | EN, DIN, JIS, AISI, BS, ASME, AISI |
| Carbon Steel AISI 1045 Angle | : | 5mm to 9mm |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Standard | Grade | C | Si | Mn | P | S | Cr |
| ASTM A29 | 1045 | 0.43-0.50 | - | 0.60-0.90 | ≤0.04 | ≤0.05 | - |
| EN 10083-2 | C45 | 0.42-0.50 | ≤0.4 | 0.50-0.90 | ≤0.03 | ≤0.035 | ≤0.4 |
| 1.1191 | |||||||
| JIS G4051 | S45C | 0.42-0.48 | 0.15-0.35 | 0.60-0.90 | ≤0.03 | ≤0.035 | – |
| Section Size mm | ≤ 16 | 17 – 40 | 41 – 100 |
| Tensile Strength Mpa | 700-850 | 6500-800 | 630-780 |
| Yield Strength Mpa | ≥ 500 | ≥430 | ≥ 370 |
| Elongation in 50mm % | ≥ 14 | ≥ 16 | ≥ 17 |
| Impact Charpy J | ≥ 30 | ≥ 30 | ≥ 30 |
| Hardness HB | 210-245 | 195-235 | 185-230 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel AISI 1045 Angle in Dubai, UAE. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your Carbon Steel AISI 1018 Angle needs!
In the automotive industry, they are employed to produce crankshafts, camshafts, and suspension components. In machinery production, they find application in the manufacturing of shafts, gears, and connecting rods. The wear and strength of the steel also serve it well in the oil and gas industry applications, such as drill bits and valve seats. AISI 1045 angles are also used in structural applications, offering stable support in frames and beams.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
