Bhavesh Steel is a prominent producer and exporter of high-performance Alloy Steel 4140 Fasteners in Dubai, UAE. While maintaining a stringent approach to quality and accuracy, the company provides fasteners that are capable of withstanding the rigorous expectations of numerous industrial applications. Leveraging cutting-edge technology and conforming to international standards, Bhavesh Steel provides each product with unparalleled durability and reliability. Reckoned for punctual delivery and outstanding customer care, the company has gained the confidence of customers in the UAE as well as the rest of the Middle East. Bhavesh Steel is your go-to ally for strong and effective fastening solutions.
4140 Alloy Steel Fasteners are made from a chromium-molybdenum alloy that is renowned for its outstanding mechanical properties and durability against wear. The common composition consists of 0.38–0.43% carbon, 0.75–1.00% manganese, 0.80–1.10% chromium, and 0.15–0.25% molybdenum. These factors are responsible for enhanced hardness, tensile strength, and toughness. The fasteners provide tensile strength of approximately 655 MPa and yield strength of about 415 MPa. With satisfactory fatigue strength and impact resistance, they are appropriate for high-stress and high-temperature applications and therefore best suited for industrial applications of high severity.
| Standard | ASTM A193, ASTM A194 / ASME SA193, SA194 GR, IS, BS |
| Specification | IS, BS, ASTM |
| Size | M 02 to M 160 |
| Length | UPTO 5 METERS |
| Grade | B 6, B 7/ B 7M, B 16, 2, 2HM, 2H, GR 6, B 7, B 7M |
| Type | Bolts, nuts, Washers, Anchor Fasteners, Stud Bolts, Eye Bolt, Stud, Threaded Rod, Cotter Pin, Socket Screw, Fine Fasteners & Spares, Foundation Fasteners, etc. |
| Element | AISI 4140 |
| Fe | 96.785 – 97.77 |
| Cr | 0.80 – 1.10 |
| Mn | 0.75 – 1.0 |
| C | 0.380 – 0.430 |
| Si | 0.15 – 0.30 |
| Mo | 0.15 – 0.25 |
| S | 0.040 |
| P | 0.035 |
| Grade AISI 4140 | Metric | Imperial |
| Tensile strength | 655 MPa | 95000 psi |
| Yield strength | 415 MPa | 60200 psi |
| Bulk modulus (Typical for steel) | 140 GPa | 20300 ksi |
| Shear modulus (typical for steel) | 80 GPa | 11600 ksi |
| Elastic modulus | 190-210 GPa | 27557-30458 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (in 50 mm) | 25.70% | 25.70% |
| Hardness, Brinell | 197 | 197 |
| Hardness, Knoop (converted from Brinell hardness) | 219 | 219 |
| Hardness, Rockwell B (converted from Brinell hardness) | 92 | 92 |
| Hardness, Rockwell C (Converted from Brinell hardness, value below normal HRC range, for comparison purposes only.) | 13 | 13 |
| Hardness, Vickers (converted from Brinell hardness) | 207 | 207 |
| Machinability (Annealed and cold drawn. Based on 100% machinability for AISI 1212 steel.) | 65 | 65 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade AISI 4140 | Metric | Imperial |
| Thermal expansion co-efficient (@ 0-100°C/32-212°F) | 12.2 µm/m°C | 6.78 µin/in°F |
| Thermal conductivity (100°C) | 42.6 W/mK | 296 BTU in/hr.ft².°F |
Alloy Steel 4140 Fasteners find applications in numerous industries because of their toughness, strength, and reliability. In the oil and gas industry, they are best suited for uses like pipelines, drilling machinery, and platforms in the sea. In the automotive sector, these fasteners are used in engine parts, drive axles, and suspension. In building and heavy equipment, they are utilized in load-carrying structures and mechanical connections. Their extreme resistance to wear and heat also renders them appropriate for application in power plants, aerospace parts, and industrial machinery where safety and durability take precedence.
