Bhavesh Steel is a reliable manufacturer and exporter of ABS DH36 Shipbuilding Steel Plates and Sheets from Dubai, UAE. Known for providing top–notch marine-grade steel, we meet the various requirements of the shipbuilding and offshore industries. Dedicated to global standards and customer satisfaction, Bhavesh Steel provides precision-engineered products with strict safety and durability standards. Our strategic position in Dubai allows us to effectively serve customers in the Middle East and worldwide, providing prompt deliveries, competitive rates, and unparalleled product reliability in shipbuilding.
ABS DH36 Shipbuilding Steel Sheets and Plates consist of carbon, manganese, phosphorus, sulfur, silicon, and trace elements such as aluminum and nitrogen, making them highly strong with excellent weldability. The mechanical properties are a minimum 355 MPa yield strength and tensile strength of 490 to 620 MPa. It has better toughness, particularly in low-temperature marine environments, and is best suited for structural applications. ABS DH36 is normalized or thermo-mechanically rolled, further improving its stress and impact resistance in harsh sea conditions to provide maximum performance and structural integrity.
STANDARD: ASTM A131, ASME SA131
PLATES QUALITY: DH36 (Dead Soft Quality)
THICKNESS: 3/16″ – 4″, 4-60mm
WIDTH: 48″ – 120″, 2000 / 2500 / 3000mm
LENGTH: 96″ – 480″, 6000 / 8000 / 10000 / 12000 mm
| Grade DH36 | C | Si | Mn | P | S | V | Al | Cr | Cu | Mo | Nb | Ni | Ti |
| 0.180 | 0.1-0.5 | 0.90-1.6 | 0.035 | 0.035 | 0.05-0.10 | 0.015 | 0.200 | 0.350 | 0.080 | 0.02-0.05 | 0.400 | 0.020 |
| Grade | Re | Rm | Elongation | |
|---|---|---|---|---|
| A50mm | A200mm | |||
| MPa | MPa | % | % | |
| DH 36 | 355 | 490/620 | 22 | 19 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Bhavesh Steel is one of the most prominent manufacturers and suppliers of superior quality ABS DH36 Shipbuilding Steel Sheet and Plates in Dubai, UAE. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
| theoretical weight | Thickness (mm) | Thickness (mm) | theoretical weight | ||
|---|---|---|---|---|---|
| Kg/m2 | Kg/ft2 | Kg/m2 | Kg/ ft2 | ||
| 47.10 | 4.376 Kg/ft2 | 6 | 25 | 196.25 | 18.962 Kg/ ft2 |
| 54.95 | 5.105 Kg/ft2 | 7 | 26 | 204.10 | 20.420 Kg/ ft2 |
| 86.35 | 8.751 Kg/ft2 | 11 | 32 | 251.20 | 25.525 Kg/ ft2 |
| 172.70 | 16.044 Kg/ft2 | 22 | 50 | 392.50 | 36.464 Kg/ ft2 |
| 62.80 | 5.834 Kg/ft2 | 8 | 28 | 219.80 | 21.879 Kg/ ft2 |
| 157.00 | 14.586 Kg/ft2 | 20 | 48 mm | 376.80 | 35.006 Kg/ ft2 |
| 78.50 | 7.293 Kg/ft2 | 10 | 30 mm | 235.50 | 23.337 Kg/ ft2 |
| 94.20 | 10.21 Kg/ft2 | 12 | 34 mm | 266.90 | 26.254 Kg/ ft2 |
| 125.60 | 11.669 Kg/ft2 | 16 | 40 mm | 314.00 | 29.172 Kg/ ft2 |
| 141.30 | 13.127 Kg/ft2 | 18 | 45 mm | 353.25 | 32.818 Kg/ ft2 |
| 109.90 | 10.939 Kg/ft2 | 14 | 35 mm | 274.75 | 27.713 Kg/ ft2 |
| 188.40 | 18.232 Kg/ft2 | 24 | |||
| Max. width | Thickness |
|---|---|
| DH36 | From to up to |
| 1370 | 1.70 to 1.80 |
| 1280 | 1.60 to 1.70 |
| 1440 | 1.80 to 1.90 |
| 1520 | 1.90 to 2.00 |
| 1170 | 1.49 to 1.60 |
| 2070 | 12.70 to 20.00 |
| 1590 | 2.00 to 2.20 |
| 1730 | 2.20 to 2.40 |
| 1880 | 2.60 to 2.80 |
| 1960 | 2.80 to 3.12 |
| 1800 | 2.40 to 2.60 |
| 2070 | 3.12 to 12.70 |
ABS DH36 Shipbuilding Steel Plates and Sheets are extensively applied in the building of ships, offshore platforms, and marine structures because they offer superior strength and resistance to corrosion. ABS DH36 Shipbuilding Steel Sheets and Plates are used to fabricate hulls, decks, bulkheads, and other load-carrying components exposed to harsh marine environments. Their superior weldability and strength qualify them for large structural assemblies in oil rigs, container ships, and naval vessels. In addition, ABS DH36 is favored during ship repairing and retrofitting operations to ensure the durability and safety of marine assets in commercial as well as defense industries.
