Serving a broad range of industrial applications, Bhavesh Steel is a reputable manufacturer and supplier of Carbon Steel F42 Forged Fittings in Dubai, United Arab Emirates. Bhavesh Steel has a solid reputation for producing high-quality forged fittings that are appropriate for high-pressure systems and satisfy international standards. These fittings are made to be precise, long-lasting, and perform exceptionally well in demanding settings. Bhavesh Steel provides specialised solutions and reliable service in the UAE and abroad, catering to sectors like oil and gas, petrochemical, power generation, and marine.
The main constituents of Carbon Steel F42 Forged Fittings are carbon and iron, with trace amounts of manganese, silicon, sulphur, and phosphorus. A good balance between strength and ductility is guaranteed by the moderate carbon content. These fittings are appropriate for high-pressure applications due to their high tensile strength, yield strength, and impact resistance. Grain structure and mechanical qualities like toughness and fatigue resistance are improved by their forged construction. Furthermore, F42 forged fittings are dependable in demanding industrial settings due to their superior weldability and machinability.
Standard : ASTM A694 / ASME SA 694
Dimensions : ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F42 | 0.13-0.20 | 0.20-0.40 | 1.20-1.60 | ≤ 0.030 | ≤ 0.020 | – | ≤ 0.30 | ≤ 0.30 | ≤ 0.25 | – | – |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 42 | 60 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F42 Forged Screwed Elbows, Street Elbow, Carbon Steel F42 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F42 Reducing Coupling, Carbon Steel F42 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F42 Threaded Bushing, Carbon Steel F42 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F42 Barrel Nipples, CS F42 Forged Threaded Boss, Carbon Steel F42 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F42 High Quality Socket weld 90° Elbow, Straight and Reducing-on-the-Tees, Forged 45° Short Radius Elbow, CS F42 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings – Socket Welding, Threaded, and Buttwelding Ends | CS F42 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F42 Coupling |
Industries that require safe and long-lasting piping connections make extensive use of carbon steel F42 forged fittings. They are perfect for refineries, offshore platforms, and oil and gas gearbox lines where corrosive and high-pressure environments are frequent. They are used in steam, water, and fuel handling systems in power plants, and they are essential for chemical processing and fluid transfer in petrochemical industries. These fittings are also utilised in heavy machinery, construction, and shipbuilding. They are crucial for safe and effective piping systems across crucial operations because of their durability, leak-proof design, and versatility with regard to welding and threading.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
