Bhavesh Steel is a prominent manufacturer and exporter of Carbon Steel DIN 2609 Pipes in Dubai, UAE. Bhavesh Steel has been committed to quality and precision, catering to a diversified customer base from various sectors. Their DIN 2609 pipes are renowned for remarkable strength, durability, and versatility, and hence are a popular choice in applications that need high-performance materials. The firm makes sure that every pipe exceeds strict global standards, thus giving customers consistent and dependable products. From construction to manufacturing and other industrial applications, Bhavesh Steel is committed to being a reliable steel supply partner.
Carbon Steel DIN 2609 Pipes cover grades including St 37-0, St 44-0, St 52-3, and TStE 285, each having different compositions and mechanical properties. For example, St 37-0 has a maximum of 0.17% carbon, 0.80% manganese, and ≤0.35% silicon, with a yield strength of 235 MPa and tensile strength of 360–510 MPa. St 44-0 contains a maximum of 0.21% carbon, with tensile strength of 550 MPa and yield strength of 420 MPa. St 52-3 offers a yield strength of 490 MPa and tensile strength of 630 MPa. TStE 285 contains a maximum of 0.18% carbon, with yield strength of 490 MPa and tensile strength of 630 MPa. These pipes undergo heat treatment processes to achieve desired mechanical properties, ensuring suitability for high-demand applications.
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
|---|---|
| DIN 2609 Grade St35-8 Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| Mild Steel DIN 2609 Grade St35-8 Welded Pipe Size | 5.0 mm – 1219.2 mm |
| DIN Gr. 2609 ST35-8 Steel EFW Pipe size | 5.0 mm – 1219.2 mm |
| Grade ST 35-8 DIN 2609 Pipe Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Carbon Steel DIN 2609 Grade ST 35-8 Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| DIN 2609 Gr St35-8 Carbon Steel Seamless Pipe Size | 3.35 mm OD To 101.6 mm OD |
| Grade ST 35-8 DIN 2609 Welded Pipe Size | 6.35 mm OD To 152 mm OD |
| CS DIN 2609 Grade St35-8 Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| DIN2609 ST35-8 Steel Pipe wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| DIN 2609 Gr St35-8 Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| DIN 2609 Gr. St 35-8 Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Low Temperature Carbon Steel DIN 2609 Grade ST 35-8 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Mild Steel DIN 2609 Grade St35-8 Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| ASME B36.19 DIN2609 Grade ST 35-8 End | Plain End, Beveled End, Treaded Pipe & Tube |
| DIN 2609 Grade St35-8 Marking | All DIN 2609 Grade ST 35-8 Carbon Steel Seamless Tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| 2609 Gr. ST35-8 Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| DIN Gr. 2609 ST35-8 Steel Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Mechanical Properties | |||||||||
| Yield Strength | Tensile Strength | Elongation A5 min | |||||||
|---|---|---|---|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage | ||||
|  |  | 360 | 480 | – | 25 | ||||
| Outer diameter and wall Thickness | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Execution | Size Range | OD Tolerance | Wall tolerance | ||||||
| Hot-rolled Pipe | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm | ||||||
| Hot-rolled peeled Pipe | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) | ||||||
| Cold Worked Pipe cold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm | ||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel DIN 2609 Pipe products in Dubai, UAE. Specializing in premium steel materials, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our diverse selection features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to reliable delivery and exceptional customer service, Jaxon Steel ensures the supply of top-grade materials that deliver excellent performance across various industrial applications. Rely on Jaxon Steel for all your Carbon Steel DIN 2609 Pipe needs.
| DIN | EN | BS | NFA | ASTM | ASME |
| DIN 2609 Grade St 37-0 | – | – | – | – | – |
Carbon Steel DIN 2609 Pipes find extensive application across industries because of their high mechanical strength. They are essentially used in the production of structural elements, bridges, and buildings where the demand is for high strength and durability. Their durability and resistance to wear and tear and ability to bear high-stress levels make them suitable for use in construction, automobile, and machinery industries. Their ease of machinability also provides easy fabrication, which helps in their extensive use in precision engineering applications.
