Bhavesh Steel is a prominent manufacturer and exporter of ASTM A572 Gr 50 Sheet and Plates in Dubai, UAE. With a deep passion for customer satisfaction and quality, Bhavesh Steel offers high-strength, low-alloy structural steel plates according to international standards. The company is renowned for its fast delivery, competitive prices, and premium material quality and serves various industries in the UAE and globally. For infrastructure, construction, and heavy equipment purposes, Bhavesh Steel is reliable for supplying ASTM A572 Gr 50 steel products according to specifications of clients.
ASTM A572 Gr 50 Plates and Sheets are produced using high-strength low-alloy steel that is highly weldable and provides better atmospheric corrosion resistance. The alloy content normally consists of carbon (up to 0.23%), manganese, phosphorus, sulfur, silicon, and small amounts of vanadium or columbium. Mechanically, this grade offers a minimum yield strength of 50 ksi (345 MPa) and tensile strength between 65 and 85 ksi (450–585 MPa). The above properties render it ideal for all kinds of structural applications demanding strength, toughness, and reliability in harsh conditions.
| Specifications | : | ASME SA572 / ASTM A572 |
|---|---|---|
| Width | : | 1500-4020mm |
| Length | : | 3000-27000mm |
| Thickness | : | 8-300mm |
| Hardness | : | As per ASME A & NACE MR 175 |
| Impact tested | : | Impact tested -52° C |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Grade | C | Mn | P | V | Ni | Co | S | Si |
| A572 Grade 50 | 0.23 | 1.35 | 0.04 | 0.06 | 0.015 | 0.05 | 0.05 | 0.4 |
| Grade | Thickness | Yield | Tensile | Elongation |
| A572 Grade 50 | 8mm-200mm | MPa -345 min | MPa – 450 | 18-21% |
| Grade | India IS | England BS | Sweden MNC | Belgium NBN | Europe EN | Russia GOST |
| A572 Grade 50 Plate | FE410WC | 43EE | SS14,14，01 | AE 295 DD | S275 J2G3 Fe430 D2 S275NL |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| GRADE | GAUGE (INCHES) | WIDTH (INCHES) | LENGTH (INCHES) |
| A572 | 0.1875 | 96 | 240/480 |
| A572 | 0.2500 | 60/96/120 | 240/480 |
| A572 | 0.3125 | 60/96/120 | 240/480 |
| A572 | 0.3750 | 60/96/120 | 240/480 |
| A572 | 0.5000 | 60/96/120 | 240/480 |
| A572 | 0.6250 | 60/96/120 | 240/480 |
| A572 | 0.7500 | 60/96/120 | 240/480 |
| A572 | 0.8750 | 60/96/120 | 240/480 |
| A572 | 1.0000 | 60/96/120 | 240/480 |
| A572 | 1.1250 | 60/96/120 | 240/480 |
| A572 | 1.2500 | 60/96/120 | 240/480 |
| A572 | 1.5000 | 60/96/120 | 240/480 |
| A572 | 1.7500 | 60/96/120 | 240/480 |
| A572 | 2.0000 | 60/96/120 | 240/480 |
| A572 | 2.2500 | 96 | 240/480 |
| A572 | 2.5000 | 96 | 240/480 |
| A572 | 2.7500 | 96 | 240/480 |
| A572 | 3.0000 | 96 | 240/480 |
| A572 | 3.2500 | 96 | 240 |
| A572 | 3.5000 | 96 | 240 |
| A572 | 3.7500 | 96 | 240 |
| A572 | 4.0000 | 96 | 240 |
| A572 | 5.0000 | 96 | 240 |
| A572 | 6.0000 | 96 | 240 |
ASTM A572 Gr 50 Plates and Sheets are used extensively in various industries for their strength, longevity, and excellent formability. In building, they are typically used in the production of bridges, buildings, and structural frames. The transport sector uses them in the production of truck trailers, railcars, and heavy machinery. They are also used in offshore and marine structures, industrial platforms, and crane booms. They are strong enough to handle high loads and extreme environmental conditions, which makes them suitable for use in areas where performance and safety are paramount. These plates also find application due to their affordability and simplicity in fabrication.
