Bhavesh Steel is a well-respected manufacturer and supplier located in Dubai, UAE, specializing in top-notch ASME SA 387 Grade 22 Class 1/2 Sheets and Plates. With a strong dedication to quality, precision, and timely delivery, Bhavesh Steel meets the needs of various industries that require high-performance alloy steel products. The company adheres to international standards and utilizes cutting-edge technology to create materials that fulfill strict operational demands. By prioritizing customer satisfaction and product excellence, Bhavesh Steel has built a solid reputation in the UAE market as a reliable provider of steel solutions.
ASME SA 387 Grade 22 Class 1/2 Sheets and Plates are alloy steels that contain about 2.0–2.5% Chromium and 0.9–1.1% Molybdenum, giving them remarkable resistance to high temperatures and pressure. These plates have a tensile strength ranging from 415–585 MPa, with Class 1 boasting a yield strength of around 205 MPa and Class 2 around 310 MPa. They also demonstrate good elongation and toughness, making them perfect for demanding structural applications. Their mechanical and chemical properties make them well-suited for high-stress, elevated-temperature environments.
| Standard | ASTM A387 / ASME SA387 |
|---|---|
| Width | 1000mm-3000mm |
| Thickness | 1.0mm – 200mm |
| Production | Hot-Rolled (HR) / Cold-Rolled (CR) |
| Grade | C | Si | Mn | P | S | Cr | Mo |
| A387 GR.22 CL.1 & 2 | 0.04-0.15 max | 0.50 max | 0.30-0.60 max | 0.035 max | 0.035 max | 1.88-2.62 max | 0.85-1.15 max |
| Grade | A387 GR.22 CL.1 & 2 | |||
| A387 GR.22 CL.1 & 2 | Thickness mm | Yield Min Mpa | Tensile Mpa | Elongation Min % |
| t≦50 | 205 | 415-585 | 18 | |
| 50<t≦200 | – | – | – | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality ASME SA 387 Grade 22 Class 1/2 Sheet and Plates​​ in Dubai, UAE. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your ASME SA 387 Grade 22 Class 1/2 Sheet and Plates​​ needs!
These alloy steel sheets and plates find extensive use in industries like power generation, petrochemical processing, oil and gas, and thermal energy production. They are mainly used in the construction of pressure vessels, boilers, heat exchangers, and other components that face extreme temperatures and pressures. Their outstanding resistance to oxidation, corrosion, and thermal fatigue guarantees a long service life and dependable performance in tough conditions. These plates are crucial for applications that require structural stability and strength, including reactors and heavy-duty processing units in industrial facilities.
Bhavesh Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Dubai, UAE.
